224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯并网发电用热车机汽柴油生活性好: 现进的汽柴油设定软件体统，独特的STC、ESTC 分级管理设定软件体统，特有方案的汽缸上边熔化室，压力喷出汽柴油，足够吸雾，熔化足够。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯来发电用打着机瞬态耐腐蚀性优等: 无暇的打着机整体上设定，加上康明斯多样的EFC操控系统，操控精度等级高，响应的時间快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯火力发电用启倾向升功效高: 整体结构结构设计紧促.外观简约时尚场地布置合理可行，工作平衡。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷舱位 QSNT. QSK19. QSK38. QSK50提供我们非之路3、步骤及美洲Tier2. Tier 3排放标准法律规定要求。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零零备件即得性好， 打着机操作及日常护理日常护理快捷，成本费用低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

马力标准 Power Range   224-310KW形式 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L外貌尺寸规格 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净高质量 Dry Weight   940kg

224-310KW康明斯发电站用起思想的基本特征：体积计算小， 缩短变高， 防雨百叶新鲜空气热处理加热，方便于通电，联通车载多媒体电原的好选择。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

发起机款式	所用工作功率(kW)Prime Power	紧急额定功率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
